AOZ9530QV
Motor Drivers
Status: Full Production
The AOZ9530QV is an integrated half-bridge gate driver with smart functions. The device includes one half-bridge gate driver, capable of driving high-side and low-side N-channel MOSFETs. Using two AOZ9530QV for single phase motor driver and three AOZ9530QV for three phase motor drivers.
Parametrics
Status | Full Production |
Package | QFN3x3-18L |
Min Vin (V) | 10.80 |
Max Vin (V) | 28 |
Internal LDO | Yes |
100% HS Duty Cycle | Yes |
OCP/SCP | Yes |
Max Output I (A) | 7 |
MOSFET RDS(ON) (mΩ) | 11 |
Max Operating Temp (°C) | 125 |
Max Operating Freq (kHz) | 30 |
SR Control | Yes |
Temp. Monitor | No |
Fault Flag | No |
Parametrics
Status | Full Production |
Package | QFN3x3-18L |
Min Vin (V) | 10.80 |
Max Vin (V) | 28 |
Internal LDO | Yes |
100% HS Duty Cycle | Yes |
OCP/SCP | Yes |
Max Output I (A) | 7 |
MOSFET RDS(ON) (mΩ) | 11 |
Max Operating Temp (°C) | 125 |
Max Operating Freq (kHz) | 30 |
SR Control | Yes |
Temp. Monitor | No |
Fault Flag | No |
Features
- Input voltage range:
- 10.8 V to 28 V - Maximum Output Current 7 A
- Adjustable Gate Drive Sink/Source Current
- Support 100% PWM Operation
- Integrated Bootstrap Diode
- Low RDS(ON) internal NFETs
- 11 mΩ for Both HS/LS - Thermal Protection
- Over Current Protection
- Short Circuit Protection
- Thermally enhanced 18-pin 3×3 QFN
Documentation
| Title | Type | Date | File |
|---|---|---|---|
| AOZ9530QV Datasheet | Datasheets | 2022-09-10 | |
| AOZ9530QV Marking | Markings | 2022-09-10 | |
| AOZ9530QV Reliability Report | Reliability Reports | 2022-09-10 | |
| QFN3x3_18L_EP2_S | Package | 2020-02-27 | |
| QFN3x3_18L_EP2_S Tape & Reel | Tape & Reel | 2024-03-15 |
Related Resources
| Title | Type | Date | File |
|---|---|---|---|
| SMM Product Highlights | Product Highlights | 2024-02-08 |
Package Details
| Package Name | Dimensions | Package Specifications | Packaging Method |
|---|---|---|---|
| QFN3x3_18L_EP2_S | 3.0x3.0x0.55 | Tape and Reel |
